Descriptions détaillées :

Total Harmonic Distortion : not more than 0.2% 20Hz- 20kHz(analog output) @+14dB into 600ohms
Frequency Response : +1-3dB 20Hz- 20kHz @+4dB into 600ohms
Dynamic Range : 110dB(Typical) DA Converter (STEREO OUT) / 105dB(Typical) AD+DA (Mic/Line IN to STEREO OUT)
Hum & Noise Level : -128dB Equivalent Input Noise (20Hz- 20kHz)
(Rs=150ohms, Input Gain=Max, Input Pad=0dB, Input Sensiivity=-60dB)
Crosstalk @1kHz : 70dB adjacent input channels / 70dB input to input
AD Conversion : 20-bit linear 64 times oversampling(Input 1- 24)
DA Conversion :
20-bit linear 8 times oversampling(ST OUT, C-R MONI OUT)
18bit linear 8 times oversampling(STUDIO MONI OUT, AUX SEND1- 8)
Internal Signal Processing : 32 bits (Dynamic Range 192dB)
Sampling Frequency : Internal 44.1/48kHz External 32kHz(-6%)- 48kHz(+6%)
Equalizer : 4-band Full Parametric Equalization
f:20Hz- 20kHz (120 points),G:+/-18dB(0.5dB step),Q:0.1- 10(41 points) All four stages
type:shelving/filter - LOW,HIGH / (40 IN,Internal EFF RTN1,2,ST OUT)
Fader : 100mm Motor Faderx21
Memory :
Scene(Total Recall) 64
Ch Library 128
EQ Library 128(40 presets+88 user presets)
Dynamic Library 128(40 presets+88 user presets)
Effect Library 128(40 presets+88 user presets)
Auto Mix 16(512KB)
Display : 320x240 pixel backlit LCD panel LCD
Stereo Meter : 21-elements x 2 LED
